Main bus control
I’ve recently started planning and designing the low
voltage renewable power system for the new house. It
will be a little while before I really get a chance to
implement the design, with boys taking up most of our
spare time, and it will take a little while to settle
into the new house. However, I’ve already started
making requirements, and I’ve hunted out some
components. Some of the initial designs are now in my
notebook.
The majority of the system will be controlled by a nice all-in-one control panel, which is designed for a top spec motor home. However I also need an additional Main bus control panel to remotely control the main battery disconnect, and monitor the status of the Main bus. The Main bus will form the heavy current backbone of the system (initially spec’d for bursts of100A), and will provide power to the main panel as well as directly supplying heavy loads such as inverters, heavy pumps or motors. The Main bus should be able to cope with bursts of current up to 100A at 12V from a sudden ~1KW load.
A few of my requirements for the Main bus control panel included:
One of my favorite websites for low voltage supplies is www.vehicle-wiring-products.co.uk. On this site I came across the following switch panel:
This fits my needs nicely, and I really do like the big red switch
My initial wiring diagram is included. This may require further tweaking, and I suspect there are a few simplifications possible, but I’ll need to look into these further:
Basic Operation
The majority of the system will be controlled by a nice all-in-one control panel, which is designed for a top spec motor home. However I also need an additional Main bus control panel to remotely control the main battery disconnect, and monitor the status of the Main bus. The Main bus will form the heavy current backbone of the system (initially spec’d for bursts of100A), and will provide power to the main panel as well as directly supplying heavy loads such as inverters, heavy pumps or motors. The Main bus should be able to cope with bursts of current up to 100A at 12V from a sudden ~1KW load.
A few of my requirements for the Main bus control panel included:
- A master switch which will remotely connect and disconnect the Battery bus from the Main bus, this will basically switch off everything
- An instant visual indication of the current state of the Main bus (Red light for Main bus power failure)
- A indication that basic verification of Main bus had been confirmed (Green light for system verified)
- A plunger push button to start the Main bus connect, and start Main bus supply verification
- A warning alarm system to alert us of a sudden power failure or a failure with Main bus verification (flashing Amber light with buzzer)
- A parallel switch, for paralleling any auxiliary batteries with the battery bus
- A timer module, which will provide a delay for Main bus verification. This is required to prevent the startup loads causing triggerging a low voltage battery or overcurrent disconnect.
One of my favorite websites for low voltage supplies is www.vehicle-wiring-products.co.uk. On this site I came across the following switch panel:
This fits my needs nicely, and I really do like the big red switch
My initial wiring diagram is included. This may require further tweaking, and I suspect there are a few simplifications possible, but I’ll need to look into these further:
Basic Operation
- Main bus is disconnected from the live Battery bus, the red switch above is down, and no lights are displayed. Everything is disconnected except those on the Hot Battery bus.
- The user lifts the main switch cover up, and lifts the main switch up. Main bus control panel is now live. The RED light will indicate that system Main bus is disconnected.
- The user starts the Main bus connect and verification system by pressing that START switch, at this point the RED light will extinguish, and the the Main bus becomes live.
- During the verification time all connected items will be powered allowing the initial burst of power to stabilize on the Main bus.
- After a 3 seconds the Main bus verification system becomes enabled. If it fails, the RED light will come on and the Alarm will start (flashing Amber light on top with buzzer). If the verification system passes testing, the GREEN light will illuminate to indicate that all systems are running normally.
- If at any time the verification system detects a problem, or the Main bus loses power, the RED light will come on and the Alarm will start.
- The Main bus can be switched off, including verification alarm system by switching off the main switch and by moving its red cover down.
- The parallel switch connects the Hot Battery bus to the auxiliary Hot Battery bus.
- I may add an optional yellow light at some point to provide a visual indication of the 3 second delay between Main bus connect and Main bus verification. Alternatively I may just illuminate both RED and GREEN light together for a short period of time.
